Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | EM10 |
| Category | Robotics |
| Performance | |
| Torque |
8.4V116.68 oz-in8.40 kg-cm0.8 N-m |
| Stall Current | ≤3 A≤3000 mAAverage |
| Physical | |
| Weight | 1.98 oz56.0 gTop 10% |
| Shape | Boxed |
| Dimensions |
L 1.89 in W 1.02 in H 1.732 in L 48.0 mm W 25.9 mm H 44.0 mm |
| Drivetrain | |
| Motor Type | Brushed |
| Gears | Plastic |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Rotational Range | 300° |
| Angle Sensor | Potentiometer |
| Control System | TTL |
| Electrical & Environment | |
| Operating Voltage | 9–13 V |
| Temperature | -10–50 °C14–122 °F |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Top 10% Lighter than 94% of 174 Large servos |
| Stall Current | Average Lower draw than 49% of 100 Large servos |
Performance Analysis
| Torque Density | 2.0836 oz-in/g |
| Torque-to-Volume Ratio | 34.95 oz-in/in³ |
| Current-per-Torque Ratio | 0.0257 A/oz-in |
| Voltage Range Width | 4.0 V 5th-highest voltage range width of 49 Kpower servos |
