Technical Specifications
Last Updated: 2026-10-24
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.12S69MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
361.14 oz-in
26.00 kg-cm
2.6 N-m
7.4V
333.36 oz-in
24.00 kg-cm
2.4 N-m
6.0V
305.58 oz-in
22.00 kg-cm
2.2 N-m
4.8V
263.91 oz-in
19.00 kg-cm
1.9 N-m
Average
|
| Speed |
8.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
7.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
6.0V
0.14 sec/60°
428.6 deg/s
71.4 RPM
4.8V
0.16 sec/60°
375.0 deg/s
62.5 RPM
Below Average
|
| Physical | |
| Weight | 2.43 oz69.0 gAverage |
| Dimensions |
L 1.57 in W 0.79 in H 1.46 in L 39.9 mm W 20.1 mm H 37.1 mm |
| Case Material | Plastic / Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 180° |
| Pulse Width | 500-2500 µs |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 61% of 1055 Digital Standard servos at 4.8V |
| Speed | Below Average Faster than 31% of 1038 Digital Standard servos at 4.8V |
| Weight | Average Lighter than 37% of 1872 Digital Standard servos |
Performance Analysis
| Shaft Power | 3.05–6.68 W |
| Power Density | 3.688 W/in³ More power-dense than 68% of 1762 Digital Standard servos |
| Torque Density | 3.8248 oz-in/g Stronger than 57% of 1048 Digital Standard servos |
| Torque-to-Volume Ratio | 145.74 oz-in/in³ Denser torque than 64% of 1053 Digital Standard servos |
| Speed-to-Weight | 0.09058 (1/sec·g) Faster than 26% of 1031 Digital Standard servos |
| Speed-Torque Trade-off | 42.23 Better balanced than 68% of 1029 Digital Standard servos |
| Torque Gain per Volt | 10.23%/V More voltage-responsive (torque) than 19% of 868 Digital Standard servos |
| Speed Gain per Volt | 16.67%/V More voltage-responsive (speed) than 56% of 868 Digital Standard servos |
| Voltage Range Width | 3.6 V Wider voltage range than 81% of 1552 Digital Standard servos |
