Technical Specifications
Last Updated: 2026-10-24
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1070MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
555.60 oz-in
40.01 kg-cm
3.9 N-m
7.4V
500.04 oz-in
36.01 kg-cm
3.5 N-m
6.0V
416.70 oz-in
30.01 kg-cm
2.9 N-m
4.8V
375.03 oz-in
27.01 kg-cm
2.6 N-m
Above Average
|
| Speed |
8.4V
0.11 sec/60°
571.4 deg/s
95.2 RPM
7.4V
0.12 sec/60°
500.0 deg/s
83.3 RPM
6.0V
0.15 sec/60°
400.0 deg/s
66.7 RPM
4.8V
0.18 sec/60°
333.3 deg/s
55.6 RPM
Below Average
|
| Physical | |
| Weight | 2.43 oz69.0 gAverage |
| Dimensions |
L 1.57 in W 0.79 in H 1.46 in L 39.9 mm W 20.1 mm H 37.1 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation Mode | Positional |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 180° |
| Pulse Width | 500-2500 µs |
| Neutral Position | 1500 µs |
| Control System | PWM |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 81% of 1055 Digital Standard servos at 4.8V |
| Speed | Below Average Faster than 19% of 1038 Digital Standard servos at 4.8V |
| Weight | Average Lighter than 37% of 1872 Digital Standard servos |
Performance Analysis
| Shaft Power | 3.85–9.78 W |
| Power Density | 5.403 W/in³ More power-dense than 81% of 1762 Digital Standard servos |
| Torque Density | 5.4352 oz-in/g Stronger than 83% of 1048 Digital Standard servos |
| Torque-to-Volume Ratio | 207.10 oz-in/in³ Denser torque than 84% of 1053 Digital Standard servos |
| Speed-to-Weight | 0.08052 (1/sec·g) Faster than 15% of 1031 Digital Standard servos |
| Speed-Torque Trade-off | 67.51 Better balanced than 88% of 1029 Digital Standard servos |
| Torque Gain per Volt | 13.37%/V More voltage-responsive (torque) than 35% of 868 Digital Standard servos |
| Speed Gain per Volt | 19.84%/V More voltage-responsive (speed) than 78% of 868 Digital Standard servos |
| Voltage Range Width | 3.6 V Wider voltage range than 81% of 1552 Digital Standard servos |
