Technical Specifications
Last Updated: 2026-07-10
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
597.27 oz-in
43.01 kg-cm
4.2 N-m
7.4V
527.82 oz-in
38.01 kg-cm
3.7 N-m
6.0V
458.37 oz-in
33.01 kg-cm
3.2 N-m
|
| Speed |
8.4V
0.13 sec/60°
461.5 deg/s
76.9 RPM
7.4V
0.15 sec/60°
400.0 deg/s
66.7 RPM
6.0V
0.18 sec/60°
333.3 deg/s
55.6 RPM
|
| Running Current | (add) |
| Stall Current | (add) |
| Physical | |
| Weight | (add) |
| Dimensions |
L 2.17 in W 0.79 in H 1.76 in L 55.1 mm W 20.1 mm H 44.7 mm |
| Case Material | Metal |
| Drivetrain | |
| Motor Type | Coreless |
| Motor Drive | (add) |
| Gears | Steel |
| Gear Spline/Teeth | (add) |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | (add) |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | 360° |
| Mechanical Limit | 180° |
| Pulse Cycle | (add) |
| Pulse Width | 1000-2000 µs |
| Neutral Position | 1520 µs |
| Dead Band | (add) |
| Refresh Rate | 333 Hz |
| Angle Sensor | (add) |
| Control System | (add) |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | (add) |
| Wire Length | (add) |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 4.71–8.50 W |
| Torque-to-Volume Ratio | 151.92 oz-in/in³ Denser torque than 63% of the 25 Digital Large servos in the database |
| Power Density | 2.816 W/in³ More power-dense than 89% of the 88 Digital Large servos in the database |
| Speed-Torque Trade-off | 82.51 Better balanced than 70% of the 31 Large servos in the database |
| Torque Gain per Volt | 12.63%/V More voltage-responsive (torque) than 29% of the 1637 Hobby servos in the database |
| Speed Gain per Volt | 16.03%/V More voltage-responsive (speed) than 51% of the 1661 Hobby servos in the database |
| Voltage Range Width | 2.4 V Wider voltage range than 24% of the 120 Digital Large servos in the database |
