Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | 491572-G92 |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
597.27 oz-in
43.01 kg-cm
4.2 N-m
7.4V
527.82 oz-in
38.01 kg-cm
3.7 N-m
6.0V
430.59 oz-in
31.01 kg-cm
3.0 N-m
|
| Speed |
8.4V
0.09 sec/60°
666.7 deg/s
111.1 RPM
7.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
6.0V
0.13 sec/60°
461.5 deg/s
76.9 RPM
|
| Physical | |
| Weight | 2.72 oz77.0 gBelow Average |
| Dimensions |
L 1.57 in W 0.79 in H 1.48 in L 39.9 mm W 20.1 mm H 37.6 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Pulse Cycle | 3.003 ms |
| Neutral Position | 1520 µs |
| Dead Band | 2 µs |
| Refresh Rate | 333 Hz |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Wire Length | 330 mm12.99 in |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Below Average Lighter than 17% of 1902 Digital Standard servos |
Performance Analysis
| Shaft Power | 6.12–12.27 W |
| Power Density | 6.685 W/in³ More power-dense than 89% of 1759 Digital Standard servos |
| Torque Density | 5.5921 oz-in/g |
| Torque-to-Volume Ratio | 234.57 oz-in/in³ |
| Speed-to-Weight | 0.09990 (1/sec·g) |
| Speed-Torque Trade-off | 55.98 |
| Voltage Range Width | 3.6 V Wider voltage range than 83% of 1539 Digital Standard servos |
