Technical Specifications
Last Updated: 2026-07-10
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
694.50 oz-in
50.01 kg-cm
4.9 N-m
7.4V
638.94 oz-in
46.01 kg-cm
4.5 N-m
6.0V
555.60 oz-in
40.01 kg-cm
3.9 N-m
|
| Speed |
8.4V
0.15 sec/60°
400.0 deg/s
66.7 RPM
7.4V
0.17 sec/60°
352.9 deg/s
58.8 RPM
6.0V
0.20 sec/60°
300.0 deg/s
50.0 RPM
|
| Running Current | (add) |
| Stall Current | (add) |
| Physical | |
| Weight | 3.10 oz88.0 g |
| Dimensions |
L 1.59 in W 0.79 in H 1.52 in L 40.4 mm W 20.1 mm H 38.6 mm |
| Case Material | Metal |
| Drivetrain | |
| Motor Type | Coreless |
| Motor Drive | (add) |
| Gears | Steel |
| Gear Spline/Teeth | (add) |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | (add) |
| Backlash | (add) |
| Control & Signal | |
| Modulation | (add) |
| Direction | (add) |
| Rotational Range | (add) |
| Mechanical Limit | (add) |
| Pulse Cycle | (add) |
| Pulse Width | (add) |
| Neutral Position | (add) |
| Dead Band | (add) |
| Refresh Rate | (add) |
| Angle Sensor | (add) |
| Control System | (add) |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | (add) |
| Wire Length | (add) |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 5.14–8.56 W |
| Torque Density | 6.3136 oz-in/g Stronger than 91% of the 1074 Standard servos in the database |
| Torque-to-Volume Ratio | 290.63 oz-in/in³ Denser torque than 95% of the 1095 Standard servos in the database |
| Power Density | 4.478 W/in³ More power-dense than 43% of the 22 GDW servos in the database |
| Speed-to-Weight | 0.05682 (1/sec·g) Faster than 1% of the 1062 Standard servos in the database |
| Speed-Torque Trade-off | 111.12 Better balanced than 98% of the 1077 Standard servos in the database |
| Torque Gain per Volt | 10.42%/V More voltage-responsive (torque) than 22% of the 869 Standard servos in the database |
| Speed Gain per Volt | 13.89%/V More voltage-responsive (speed) than 41% of the 884 Standard servos in the database |
| Voltage Range Width | 2.4 V Wider voltage range than 25% of the 21 GDW servos in the database |
