Technical Specifications
Last Updated: 2026-07-10
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
125.01 oz-in
9.00 kg-cm
0.9 N-m
7.4V
156.96 oz-in
11.30 kg-cm
1.1 N-m
6.0V
179.18 oz-in
12.90 kg-cm
1.3 N-m
|
| Speed |
8.4V
0.13 sec/60°
461.5 deg/s
76.9 RPM
7.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
|
| Running Current | (add) |
| Stall Current | (add) |
| Physical | |
| Weight | (add) |
| Dimensions |
L 1.40 in W 0.59 in H 1.16 in L 35.6 mm W 15.0 mm H 29.5 mm |
| Case Material | (add) |
| Drivetrain | |
| Motor Type | Coreless |
| Motor Drive | (add) |
| Gears | (add) |
| Gear Spline/Teeth | (add) |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | (add) |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | (add) |
| Mechanical Limit | (add) |
| Pulse Cycle | (add) |
| Pulse Width | (add) |
| Neutral Position | (add) |
| Dead Band | (add) |
| Refresh Rate | (add) |
| Angle Sensor | (add) |
| Control System | (add) |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | (add) |
| Wire Length | 600 mm23.62 in |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 1.78–3.68 W |
| Torque-to-Volume Ratio | 187.00 oz-in/in³ Denser torque than 91% of the 224 Digital Mini servos in the database |
| Power Density | 3.842 W/in³ More power-dense than 83% of the 425 Digital Mini servos in the database |
| Speed-Torque Trade-off | 16.13 Better balanced than 87% of the 223 Digital Mini servos in the database |
| Torque Gain per Volt | -12.60%/V More voltage-responsive (torque) than 0% of the 190 Digital Mini servos in the database |
| Speed Gain per Volt | -12.82%/V More voltage-responsive (speed) than 2% of the 190 Digital Mini servos in the database |
| Voltage Range Width | 2.4 V Wider voltage range than 59% of the 288 Digital Mini servos in the database |
