Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
83.34 oz-in
6.00 kg-cm
0.6 N-m
7.4V
76.40 oz-in
5.50 kg-cm
0.5 N-m
6.0V
69.45 oz-in
5.00 kg-cm
0.5 N-m
|
| Speed |
8.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
7.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
|
| Physical | |
| Weight | 0.88 oz25.0 gBelow Average |
| Dimensions |
L 1.18 in W 0.39 in H 1.18 in L 30.0 mm W 9.9 mm H 30.0 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Control & Signal | |
| Modulation | Digital |
| Neutral Position | 1520 µs |
| Refresh Rate | 333 Hz |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Below Average Lighter than 33% of 103 Digital Slim servos |
Performance Analysis
| Shaft Power | 1.07–1.54 W |
| Power Density | 2.838 W/in³ More power-dense than 44% of 99 Digital Slim servos |
| Torque Density | 2.7780 oz-in/g |
| Torque-to-Volume Ratio | 127.89 oz-in/in³ |
| Speed-to-Weight | 0.33333 (1/sec·g) |
| Speed-Torque Trade-off | 8.33 |
| Voltage Range Width | 3.6 V Wider voltage range than 78% of 93 Digital Slim servos |
