Technical Specifications
Last Updated: 2026-07-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
348.00 oz-in
25.06 kg-cm
2.5 N-m
4.8V
262.00 oz-in
18.87 kg-cm
1.9 N-m
|
| Speed |
6.0V
0.13 sec/60°
461.5 deg/s
76.9 RPM
4.8V
0.16 sec/60°
375.0 deg/s
62.5 RPM
|
| Physical | |
| Weight | 4.80 oz136.0 gBottom 10% |
| Dimensions |
L 1.72 in W 0.79 in H 1.69 in L 43.7 mm W 20.1 mm H 42.9 mm |
| Drivetrain | |
| Motor Type | 3-pole |
| Gears | Metal |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 80° |
| Pulse Width | 1500-1900 µs |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Bottom 10% Lighter than 4% of 143 Digital Large servos |
Performance Analysis
| Shaft Power | 3.03–4.95 W |
| Power Density | 2.155 W/in³ More power-dense than 75% of 108 Digital Large servos |
| Torque Density | 1.9265 oz-in/g |
| Torque-to-Volume Ratio | 114.09 oz-in/in³ |
| Speed-to-Weight | 0.04596 (1/sec·g) |
| Speed-Torque Trade-off | 41.92 |
