Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | 27115 |
| Category | Hobby |
| Discontinued | Yes |
| Performance | |
| Torque |
7.4V
365.31 oz-in
26.31 kg-cm
2.6 N-m
6.0V
320.86 oz-in
23.10 kg-cm
2.3 N-m
Above Average
|
| Speed |
7.4V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
6.0V
0.08 sec/60°
750.0 deg/s
125.0 RPM
Above Average
|
| Physical | |
| Weight | 2.57 oz73.0 gBelow Average |
| Dimensions |
L 1.56 in W 0.79 in H 1.52 in L 39.6 mm W 20.1 mm H 38.6 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Metal |
| Gear Spline/Teeth | 25 T estimate |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Electrical & Environment | |
| Operating Voltage | 6–7.4 V |
| Water Rating | Water Resistant |
| Origin | |
| Country of Origin | USA |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 72% of 1060 Digital Standard servos at 6.0V |
| Speed | Above Average Faster than 88% of 1045 Digital Standard servos at 6.0V |
| Weight | Below Average Lighter than 25% of 1880 Digital Standard servos |
Performance Analysis
| Shaft Power | 7.42–11.26 W |
| Power Density | 6.010 W/in³ More power-dense than 85% of 1768 Digital Standard servos |
| Torque Density | 4.3953 oz-in/g Stronger than 69% of 1053 Digital Standard servos |
| Torque-to-Volume Ratio | 171.29 oz-in/in³ Denser torque than 74% of 1058 Digital Standard servos |
| Speed-to-Weight | 0.17123 (1/sec·g) Faster than 82% of 1038 Digital Standard servos |
| Speed-Torque Trade-off | 25.67 Better balanced than 45% of 1034 Digital Standard servos |
| Torque Gain per Volt | 9.90%/V More voltage-responsive (torque) than 18% of 873 Digital Standard servos |
| Speed Gain per Volt | 23.81%/V More voltage-responsive (speed) than 92% of 874 Digital Standard servos |
| Voltage Range Width | 1.4 V Wider voltage range than 28% of 1560 Digital Standard servos |
