Technical Specifications
Last Updated: 2026-10-09
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | 27107 |
| Category | Hobby |
| Discontinued | Yes |
| Performance | |
| Torque |
7.4V
294.47 oz-in
21.20 kg-cm
2.1 N-m
6.0V
240.30 oz-in
17.30 kg-cm
1.7 N-m
Average
|
| Speed |
7.4V
0.07 sec/60°
857.1 deg/s
142.9 RPM
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
Above Average
|
| Physical | |
| Weight | 2.57 oz72.8 gBelow Average |
| Dimensions |
L 1.56 in W 0.79 in H 1.52 in L 39.6 mm W 20.1 mm H 38.6 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Metal |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Electrical & Environment | |
| Operating Voltage | 6–7.4 V |
| Power Source | 2S LiPo |
| Water Rating | Water Resistant |
| Origin | |
| Country of Origin | USA |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 55% of 1043 Digital Standard servos at 6.0V |
| Speed | Above Average Faster than 81% of 1041 Digital Standard servos at 6.0V |
| Weight | Below Average Lighter than 26% of 1902 Digital Standard servos |
Performance Analysis
| Shaft Power | 4.94–7.78 W |
| Power Density | 4.152 W/in³ More power-dense than 72% of 1759 Digital Standard servos |
| Torque Density | 3.3008 oz-in/g Stronger than 47% of 1036 Digital Standard servos |
| Torque-to-Volume Ratio | 128.28 oz-in/in³ Denser torque than 56% of 1042 Digital Standard servos |
| Speed-to-Weight | 0.15263 (1/sec·g) Faster than 72% of 1033 Digital Standard servos |
| Speed-Torque Trade-off | 21.63 Better balanced than 39% of 1031 Digital Standard servos |
| Torque Gain per Volt | 16.10%/V More voltage-responsive (torque) than 54% of 850 Digital Standard servos |
| Speed Gain per Volt | 20.40%/V More voltage-responsive (speed) than 79% of 871 Digital Standard servos |
| Voltage Range Width | 1.4 V Wider voltage range than 28% of 1539 Digital Standard servos |
