Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | 27111 |
| Category | Hobby |
| Discontinued | Yes |
| Performance | |
| Torque |
7.4V
208.35 oz-in
15.00 kg-cm
1.5 N-m
6.0V
194.46 oz-in
14.00 kg-cm
1.4 N-m
Average
|
| Speed |
7.4V
0.14 sec/60°
428.6 deg/s
71.4 RPM
6.0V
0.16 sec/60°
375.0 deg/s
62.5 RPM
Below Average
|
| Physical | |
| Weight | 1.98 oz56.0 gAbove Average |
| Dimensions |
L 1.62 in W 0.79 in H 1.50 in L 41.1 mm W 20.1 mm H 38.1 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | Brushed |
| Gears | Metal |
| Gear Spline/Teeth | 25 T estimate |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Electrical & Environment | |
| Operating Voltage | 6–7.4 V |
| Regulator Type | BEC |
| Water Rating | Water Resistant |
| Connectivity | |
| Connector | Futaba J |
| Origin | |
| Country of Origin | USA |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 44% of 1043 Digital Standard servos at 6.0V |
| Speed | Below Average Faster than 30% of 1041 Digital Standard servos at 6.0V |
| Weight | Above Average Lighter than 71% of 1902 Digital Standard servos |
Performance Analysis
| Shaft Power | 2.25–2.75 W |
| Power Density | 1.433 W/in³ More power-dense than 30% of 1759 Digital Standard servos |
| Torque Density | 3.4725 oz-in/g Stronger than 50% of 1036 Digital Standard servos |
| Torque-to-Volume Ratio | 101.30 oz-in/in³ Denser torque than 42% of 1042 Digital Standard servos |
| Speed-to-Weight | 0.11161 (1/sec·g) Faster than 47% of 1033 Digital Standard servos |
| Speed-Torque Trade-off | 31.11 Better balanced than 54% of 1031 Digital Standard servos |
| Torque Gain per Volt | 5.10%/V More voltage-responsive (torque) than 3% of 850 Digital Standard servos |
| Speed Gain per Volt | 10.21%/V More voltage-responsive (speed) than 18% of 871 Digital Standard servos |
| Voltage Range Width | 1.4 V Wider voltage range than 27% of 1539 Digital Standard servos |
