Technical Specifications
Last Updated: 2026-07-10
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
229.14 oz-in
16.50 kg-cm
1.6 N-m
4.8V
177.76 oz-in
12.80 kg-cm
1.3 N-m
|
| Speed |
8.4V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
4.8V
0.10 sec/60°
600.0 deg/s
100.0 RPM
|
| Running Current | (add) |
| Stall Current | (add) |
| Physical | |
| Weight | 1.76 oz50.0 g |
| Dimensions |
L 1.57 in W 0.79 in H 1.12 in L 39.9 mm W 20.1 mm H 28.4 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Motor Drive | (add) |
| Gears | Metal |
| Gear Spline/Teeth | (add) |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | Dual Bearings |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | 180° |
| Mechanical Limit | (add) |
| Pulse Cycle | (add) |
| Pulse Width | 500-2500 µs |
| Neutral Position | 1500 µs |
| Dead Band | 3 µs |
| Refresh Rate | (add) |
| Angle Sensor | (add) |
| Control System | PWM |
| Programmable | No |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | JR (Universal) |
| Wire Length | 300 mm11.81 in |
| Origin | |
| Country of Origin | (add) |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Torque Density | 3.5552 oz-in/g Stronger than 73% of the 95 Digital Low Profile servos in the database |
| Torque-to-Volume Ratio | 127.96 oz-in/in³ Denser torque than 71% of the 95 Digital Low Profile servos in the database |
| Speed-to-Weight | 0.20000 (1/sec·g) Faster than 47% of the 95 Digital Low Profile servos in the database |
| Speed-Torque Trade-off | 17.78 Better balanced than 68% of the 93 Digital Low Profile servos in the database |
| Torque Gain per Volt | 8.03%/V More voltage-responsive (torque) than 12% of the 74 Digital Low Profile servos in the database |
| Speed Gain per Volt | 18.52%/V More voltage-responsive (speed) than 82% of the 78 Digital Low Profile servos in the database |
| Voltage Range Width | 3.6 V Wider voltage range than 62% of the 164 Digital Low Profile servos in the database |
| Dead-Band-to-Pulse-Width Ratio | 0.0015 Finer dead band than 47% of the 39 Digital Low Profile servos in the database |
