Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | M08YY |
| Category | Hobby |
| Performance | |
| Torque |
7.4V102.79 oz-in7.40 kg-cm0.7 N-m |
| Speed |
8.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
7.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
|
| Physical | |
| Weight | 0.46 oz13.0 gAverage |
| Dimensions |
L 0.93 in W 0.46 in H 0.80 in L 23.6 mm W 11.7 mm H 20.3 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | Brushed |
| Gears | Metal |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Angle Sensor | Potentiometer |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Average Lighter than 36% of 597 Digital Micro servos |
Performance Analysis
| Shaft Power | 1.73 W |
| Power Density | 5.049 W/in³ More power-dense than 81% of 563 Digital Micro servos |
| Torque Density | 7.9069 oz-in/g |
| Torque-to-Volume Ratio | 300.35 oz-in/in³ |
| Speed-to-Weight | 0.69930 (1/sec·g) |
| Speed-Torque Trade-off | 11.31 |
| Voltage Range Width | 3.6 V Wider voltage range than 86% of 496 Digital Micro servos |
