Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | HC1510 |
| Category | Hobby |
| Performance | |
| Torque |
7.4V222.20 oz-in16.00 kg-cm1.6 N-m |
| Speed |
7.4V0.13 sec/60°461.5 deg/s76.9 RPM |
| Stall Current | ≤5 A≤5000 mABelow Average |
| Physical | |
| Weight | 2.17 oz61.5 gBelow Average |
| Dimensions |
L 1.57 in W 0.79 in H 1.134 in L 39.9 mm W 20.1 mm H 28.8 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Titanium |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Backlash | 0.500° |
| Control & Signal | |
| Rotational Range | 120° |
| Dead Band | 3 µs |
| Angle Sensor | Potentiometer |
| Control System | PWM |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Temperature | -10–50 °C14–122 °F |
| Water Rating | IP42 |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Below Average Lighter than 16% of 414 Low Profile servos |
| Stall Current | Below Average Lower draw than 15% of 90 Low Profile servos |
Performance Analysis
| Shaft Power | 3.16 W |
| Power Density | 2.247 W/in³ More power-dense than 66% of 62 Kpower servos |
| Torque Density | 3.6130 oz-in/g |
| Torque-to-Volume Ratio | 157.98 oz-in/in³ |
| Speed-to-Weight | 0.12508 (1/sec·g) |
| Speed-Torque Trade-off | 28.89 |
| Current-per-Torque Ratio | 0.0225 A/oz-in |
| Voltage Range Width | 3.6 V Wider voltage range than 65% of 49 Kpower servos |
| Backlash-to-Range Ratio | 0.00417 Tighter backlash than 30% of 106 Hobby servos |
