Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Category | Hobby |
| Performance | |
| Torque |
6.0V83.34 oz-in6.00 kg-cm0.6 N-m |
| Speed |
6.0V0.08 sec/60°750.0 deg/s125.0 RPM |
| Physical | |
| Weight | 1.01 oz28.5 gBelow Average |
| Dimensions |
L 1.42 in W 0.59 in H 1.14 in L 36.1 mm W 15.0 mm H 29.0 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Metal |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Below Average Lighter than 33% of 466 Digital Mini servos |
Performance Analysis
| Shaft Power | 1.93 W |
| Power Density | 2.017 W/in³ More power-dense than 62% of 440 Digital Mini servos |
| Torque Density | 2.9242 oz-in/g |
| Torque-to-Volume Ratio | 87.26 oz-in/in³ |
| Speed-to-Weight | 0.43860 (1/sec·g) |
| Speed-Torque Trade-off | 6.67 |
