Technical Specifications
Last Updated: 2026-10-23
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
750.06 oz-in
54.01 kg-cm
5.3 N-m
7.4V
694.50 oz-in
50.01 kg-cm
4.9 N-m
6.0V
583.38 oz-in
42.01 kg-cm
4.1 N-m
Below Average
|
| Speed |
8.4V
0.12 sec/60°
521.7 deg/s
87.0 RPM
7.4V
0.13 sec/60°
461.5 deg/s
76.9 RPM
6.0V
0.16 sec/60°
387.1 deg/s
64.5 RPM
Above Average
|
| Physical | |
| Weight | 5.15 oz146.0 gTop 10% |
| Dimensions |
L 2.59 in W 1.18 in H 2.26 in L 65.8 mm W 30.0 mm H 57.4 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | DC |
| Gears | Metal |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Below Average Stronger than 30% of 88 Digital Giant servos at 6.0V |
| Speed | Above Average Faster than 81% of 89 Digital Giant servos at 6.0V |
| Weight | Top 10% Lighter than 93% of 168 Digital Giant servos |
Performance Analysis
| Shaft Power | 6.96–12.06 W |
| Power Density | 1.746 W/in³ More power-dense than 50% of 136 Digital Giant servos |
| Torque Density | 3.9958 oz-in/g Stronger than 57% of 85 Digital Giant servos |
| Torque-to-Volume Ratio | 84.46 oz-in/in³ Denser torque than 34% of 88 Digital Giant servos |
| Speed-to-Weight | 0.04419 (1/sec·g) Faster than 94% of 86 Digital Giant servos |
| Speed-Torque Trade-off | 90.42 Better balanced than 30% of 85 Digital Giant servos |
| Torque Gain per Volt | 11.90%/V More voltage-responsive (torque) than 54% of 69 Digital Giant servos |
| Speed Gain per Volt | 14.49%/V More voltage-responsive (speed) than 73% of 71 Digital Giant servos |
| Voltage Range Width | 2.4 V Wider voltage range than 37% of 160 Digital Giant servos |
Similar Active Servos
Reviews (1)
Includes 1 review aggregated from around the web.
There are very few reviews for this servo on the web. A Reddit user calls it reliable and cheap and says he has not had any problems yet.
