Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1222MGW |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
83.34 oz-in
6.00 kg-cm
0.6 N-m
7.4V
75.01 oz-in
5.40 kg-cm
0.5 N-m
6.0V
63.89 oz-in
4.60 kg-cm
0.5 N-m
4.8V
55.56 oz-in
4.00 kg-cm
0.4 N-m
Average
|
| Speed |
8.4V
0.09 sec/60°
666.7 deg/s
111.1 RPM
7.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.14 sec/60°
428.6 deg/s
71.4 RPM
Below Average
|
| Physical | |
| Weight | 0.78 oz22.0 gAverage |
| Dimensions |
L 1.16 in W 0.55 in H 1.14 in L 29.5 mm W 14.0 mm H 29.0 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Titanium |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Pulse Width | 900-2100 µs |
| Neutral Position | 1500 µs |
| Control System | PWM |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Water Rating | IP67 |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 49% of 262 Digital Mini servos at 4.8V |
| Speed | Below Average Faster than 29% of 263 Digital Mini servos at 4.8V |
| Weight | Average Lighter than 64% of 466 Digital Mini servos |
Performance Analysis
| Shaft Power | 0.73–1.71 W |
| Power Density | 2.354 W/in³ More power-dense than 67% of 440 Digital Mini servos |
| Torque Density | 2.5255 oz-in/g Stronger than 57% of 258 Digital Mini servos |
| Torque-to-Volume Ratio | 76.39 oz-in/in³ Denser torque than 48% of 262 Digital Mini servos |
| Speed-to-Weight | 0.32468 (1/sec·g) Faster than 49% of 259 Digital Mini servos |
| Speed-Torque Trade-off | 7.78 Better balanced than 54% of 261 Digital Mini servos |
| Torque Gain per Volt | 13.89%/V More voltage-responsive (torque) than 27% of 232 Digital Mini servos |
| Speed Gain per Volt | 15.43%/V More voltage-responsive (speed) than 44% of 235 Digital Mini servos |
| Voltage Range Width | 3.6 V Wider voltage range than 84% of 351 Digital Mini servos |
