Technical Specifications
Last Updated: 2026-10-25
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1023MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
97.23 oz-in
7.00 kg-cm
0.7 N-m
7.4V
90.29 oz-in
6.50 kg-cm
0.6 N-m
6.0V
72.23 oz-in
5.20 kg-cm
0.5 N-m
4.8V
62.51 oz-in
4.50 kg-cm
0.4 N-m
Above Average
|
| Speed |
8.4V
0.09 sec/60°
666.7 deg/s
111.1 RPM
7.4V
0.10 sec/60°
600.0 deg/s
100.0 RPM
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.14 sec/60°
428.6 deg/s
71.4 RPM
Below Average
|
| Physical | |
| Weight | 0.81 oz23.0 gBottom 10% |
| Dimensions |
L 1.18 in W 0.39 in H 1.20 in L 30.0 mm W 9.9 mm H 30.5 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Pulse Width | 900-2100 µs |
| Neutral Position | 1500 µs |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 82% of 363 Digital Micro servos at 4.8V |
| Speed | Below Average Faster than 24% of 361 Digital Micro servos at 4.8V |
| Weight | Bottom 10% Lighter than 6% of 665 Digital Micro servos |
Performance Analysis
| Shaft Power | 0.83–2.00 W |
| Power Density | 3.617 W/in³ More power-dense than 68% of 625 Digital Micro servos |
| Torque Density | 2.7178 oz-in/g Stronger than 59% of 363 Digital Micro servos |
| Torque-to-Volume Ratio | 113.19 oz-in/in³ Denser torque than 74% of 359 Digital Micro servos |
| Speed-to-Weight | 0.31056 (1/sec·g) Faster than 8% of 361 Digital Micro servos |
| Speed-Torque Trade-off | 8.75 Better balanced than 85% of 358 Digital Micro servos |
| Torque Gain per Volt | 15.43%/V More voltage-responsive (torque) than 36% of 302 Digital Micro servos |
| Speed Gain per Volt | 15.43%/V More voltage-responsive (speed) than 33% of 305 Digital Micro servos |
| Voltage Range Width | 3.6 V Wider voltage range than 85% of 553 Digital Micro servos |
