Technical Specifications
Last Updated: 2026-10-25
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1026MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
152.79 oz-in
11.00 kg-cm
1.1 N-m
7.4V
138.90 oz-in
10.00 kg-cm
1.0 N-m
6.0V
113.90 oz-in
8.20 kg-cm
0.8 N-m
Top 10%
|
| Speed |
8.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
7.4V
0.12 sec/60°
500.0 deg/s
83.3 RPM
6.0V
0.15 sec/60°
400.0 deg/s
66.7 RPM
Below Average
|
| Physical | |
| Weight | 0.92 oz26.0 gBottom 10% |
| Dimensions |
L 1.14 in W 0.39 in H 1.20 in L 29.0 mm W 9.9 mm H 30.5 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Mechanical Limit | 180° |
| Pulse Width | 900-2100 µs |
| Neutral Position | 1500 µs |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Temperature | 0–55 °C32–131 °F |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Top 10% Stronger than 96% of 349 Digital Micro servos at 6.0V |
| Speed | Below Average Faster than 16% of 347 Digital Micro servos at 6.0V |
| Weight | Bottom 10% Lighter than 2% of 597 Digital Micro servos |
Performance Analysis
| Shaft Power | 1.40–2.57 W |
| Power Density | 4.814 W/in³ More power-dense than 80% of 563 Digital Micro servos |
| Torque Density | 4.3808 oz-in/g Stronger than 90% of 349 Digital Micro servos |
| Torque-to-Volume Ratio | 213.49 oz-in/in³ Denser torque than 93% of 345 Digital Micro servos |
| Speed-to-Weight | 0.25641 (1/sec·g) Faster than 2% of 347 Digital Micro servos |
| Speed-Torque Trade-off | 17.09 5th-highest speed-torque trade-off of 345 Digital Micro servos |
| Torque Gain per Volt | 14.23%/V More voltage-responsive (torque) than 32% of 290 Digital Micro servos |
| Speed Gain per Volt | 15.16%/V More voltage-responsive (speed) than 29% of 295 Digital Micro servos |
| Voltage Range Width | 2.4 V Wider voltage range than 60% of 496 Digital Micro servos |
