Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.11T46MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
118.07 oz-in
8.50 kg-cm
0.8 N-m
7.4V
104.18 oz-in
7.50 kg-cm
0.7 N-m
6.0V
83.34 oz-in
6.00 kg-cm
0.6 N-m
4.8V
69.45 oz-in
5.00 kg-cm
0.5 N-m
Average
|
| Speed |
8.4V
0.07 sec/60°
923.1 deg/s
153.8 RPM
7.4V
0.07 sec/60°
857.1 deg/s
142.9 RPM
6.0V
0.08 sec/60°
750.0 deg/s
125.0 RPM
4.8V
0.09 sec/60°
666.7 deg/s
111.1 RPM
Above Average
|
| Physical | |
| Weight | 1.45 oz41.0 gBottom 10% |
| Dimensions |
L 1.40 in W 0.59 in H 1.543 in L 35.6 mm W 15.0 mm H 39.2 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Titanium |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 64% of 284 Digital Mini servos at 4.8V |
| Speed | Above Average Faster than 71% of 288 Digital Mini servos at 4.8V |
| Weight | Bottom 10% Lighter than 9% of 490 Digital Mini servos |
Performance Analysis
| Shaft Power | 1.43–3.36 W |
| Power Density | 2.635 W/in³ More power-dense than 66% of 468 Digital Mini servos |
| Torque Density | 1.6939 oz-in/g Stronger than 23% of 280 Digital Mini servos |
| Torque-to-Volume Ratio | 54.49 oz-in/in³ Denser torque than 28% of 282 Digital Mini servos |
| Speed-to-Weight | 0.27100 (1/sec·g) Faster than 30% of 284 Digital Mini servos |
| Speed-Torque Trade-off | 6.25 Better balanced than 45% of 282 Digital Mini servos |
| Torque Gain per Volt | 19.45%/V More voltage-responsive (torque) than 71% of 252 Digital Mini servos |
| Speed Gain per Volt | 10.68%/V More voltage-responsive (speed) than 16% of 258 Digital Mini servos |
| Voltage Range Width | 3.6 V Wider voltage range than 82% of 396 Digital Mini servos |
