Technical Specifications
Last Updated: 2026-10-23
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1053MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
277.80 oz-in
20.00 kg-cm
2.0 N-m
7.4V
250.02 oz-in
18.00 kg-cm
1.8 N-m
6.0V
208.35 oz-in
15.00 kg-cm
1.5 N-m
4.8V
180.57 oz-in
13.00 kg-cm
1.3 N-m
Average
|
| Speed |
8.4V
0.17 sec/60°
352.9 deg/s
58.8 RPM
7.4V
0.20 sec/60°
300.0 deg/s
50.0 RPM
6.0V
0.21 sec/60°
285.7 deg/s
47.6 RPM
4.8V
0.23 sec/60°
260.9 deg/s
43.5 RPM
Bottom 10%
|
| Physical | |
| Weight | 2.22 oz63.0 gAverage |
| Dimensions |
L 1.57 in W 0.79 in H 1.67 in L 39.9 mm W 20.1 mm H 42.4 mm |
| Case Material | Aluminum / Plastic |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Titanium |
| Gear Spline/Teeth | 25 T |
| Rotation Mode | Positional |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 180° |
| Pulse Width | 500-2500 µs |
| Neutral Position | 1500 µs |
| Control System | PWM |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Average Stronger than 41% of 1055 Digital Standard servos at 4.8V |
| Speed | Bottom 10% Faster than 4% of 1038 Digital Standard servos at 4.8V |
| Weight | Average Lighter than 49% of 1872 Digital Standard servos |
Performance Analysis
| Shaft Power | 1.45–3.02 W |
| Power Density | 1.459 W/in³ More power-dense than 30% of 1762 Digital Standard servos |
| Torque Density | 2.8662 oz-in/g Stronger than 40% of 1048 Digital Standard servos |
| Torque-to-Volume Ratio | 87.18 oz-in/in³ Denser torque than 36% of 1053 Digital Standard servos |
| Speed-to-Weight | 0.06901 (1/sec·g) Faster than 6% of 1031 Digital Standard servos |
| Speed-Torque Trade-off | 41.53 Better balanced than 67% of 1029 Digital Standard servos |
| Torque Gain per Volt | 14.96%/V More voltage-responsive (torque) than 45% of 868 Digital Standard servos |
| Speed Gain per Volt | 9.80%/V More voltage-responsive (speed) than 15% of 868 Digital Standard servos |
| Voltage Range Width | 3.6 V Wider voltage range than 82% of 1552 Digital Standard servos |
