Technical Specifications
Last Updated: 2026-11-05
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.004 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
7.64 oz-in
0.55 kg-cm
0.1 N-m
5.0V
7.64 oz-in
0.55 kg-cm
0.1 N-m
4.2V
6.25 oz-in
0.45 kg-cm
0.0 N-m
|
| Speed |
6.0V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
5.0V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
4.2V
0.08 sec/60°
750.0 deg/s
125.0 RPM
|
| Physical | |
| Weight | 0.13 oz3.8 gAverage |
| Dimensions |
L 0.79 in W 0.33 in H 0.68 in L 20.1 mm W 8.4 mm H 17.3 mm |
| Case Material | Plastic |
| Drivetrain | |
| Gears | Plastic |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Bushing |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 90° |
| Pulse Width | 1000-2000 µs |
| Angle Sensor | Potentiometer |
| Programmable | No |
| Electrical & Environment | |
| Operating Voltage | 3.6–6 V |
| Power Source | LiPo |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Average Lighter than 58% of 89 Digital Nano servos |
Performance Analysis
| Shaft Power | 0.14–0.24 W |
| Power Density | 1.328 W/in³ More power-dense than 44% of 81 Digital Nano servos |
| Torque Density | 1.6447 oz-in/g |
| Torque-to-Volume Ratio | 35.26 oz-in/in³ |
| Speed-to-Weight | 3.28947 (1/sec·g) |
| Speed-Torque Trade-off | 0.50 |
| Voltage Range Width | 2.4 V Wider voltage range than 70% of 77 Digital Nano servos |
