Technical Specifications
Last Updated: 2026-10-23
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.0037 |
| Category | Hobby |
| Performance | |
| Torque |
4.8V11.11 oz-in0.80 kg-cm0.1 N-m |
| Speed |
4.8V0.12 sec/60°500.0 deg/s83.3 RPM |
| Physical | |
| Weight | 0.13 oz3.7 gTop 10% |
| Dimensions |
L 0.78 in W 0.33 in H 0.84 in L 19.8 mm W 8.4 mm H 21.3 mm |
| Drivetrain | |
| Gears | Plastic |
| Rotation/Support | Bushing |
| Control & Signal | |
| Modulation | Analog |
| Rotational Range | 90° |
| Pulse Width | 1000-2000 µs |
| Electrical & Environment | |
| Operating Voltage | 3–6 V |
| Power Source | LiPo |
| Temperature | 0–55 °C32–131 °F |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Top 10% Lighter than 90% of 372 Analog Micro servos |
Performance Analysis
| Shaft Power | 0.17 W |
| Power Density | 0.792 W/in³ More power-dense than 42% of 357 Analog Micro servos |
| Torque Density | 3.0027 oz-in/g |
| Torque-to-Volume Ratio | 51.38 oz-in/in³ |
| Speed-to-Weight | 2.25225 (1/sec·g) |
| Speed-Torque Trade-off | 1.33 |
| Voltage Range Width | 3.0 V Wider voltage range than 97% of 197 Analog Micro servos |
