Technical Specifications
Last Updated: 2026-10-09
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.002 |
| Category | Hobby |
| Performance | |
| Torque |
5.0V
1.11 oz-in
0.08 kg-cm
0.0 N-m
3.5V
0.83 oz-in
0.06 kg-cm
0.0 N-m
Bottom 10%
|
| Speed |
5.0V
0.05 sec/60°
1,200.0 deg/s
200.0 RPM
3.5V
0.07 sec/60°
857.1 deg/s
142.9 RPM
Above Average
|
| Physical | |
| Weight | 0.06 oz1.8 gAbove Average |
| Dimensions |
L 0.53 in W 0.24 in H 0.63 in L 13.5 mm W 6.1 mm H 16.0 mm |
| Drivetrain | |
| Gears | Plastic |
| Control & Signal | |
| Modulation | Digital |
| Electrical & Environment | |
| Operating Voltage | 3.5–5 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Bottom 10% Stronger than 4% of 29 Nano servos at 3.5V |
| Speed | Above Average Faster than 86% of 29 Nano servos at 3.5V |
| Weight | Above Average Lighter than 83% of 41 Digital Nano servos |
Performance Analysis
| Shaft Power | 0.02–0.04 W |
| Power Density | 0.512 W/in³ More power-dense than 21% of 35 Digital Nano servos |
| Torque Density | 0.4611 oz-in/g Stronger than 0% of 39 Kavan servos |
| Torque-to-Volume Ratio | 10.36 oz-in/in³ Denser torque than 0% of 39 Kavan servos |
| Speed-to-Weight | 7.93651 (1/sec·g) 1st-highest speed-to-weight of 39 Kavan servos |
| Speed-Torque Trade-off | 0.06 Better balanced than 0% of 39 Kavan servos |
| Torque Gain per Volt | 22.49%/V 2nd-highest torque gain per volt of 39 Kavan servos |
| Speed Gain per Volt | 26.67%/V 1st-highest speed gain per volt of 39 Kavan servos |
| Voltage Range Width | 1.5 V Wider voltage range than 48% of 32 Digital Nano servos |
