Technical Specifications
Last Updated: 2026-07-28
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
4.2V
1.04 oz-in
0.07 kg-cm
0.0 N-m
3.7V
0.90 oz-in
0.06 kg-cm
0.0 N-m
|
| Speed |
4.2V
0.05 sec/60°
1,200.0 deg/s
200.0 RPM
3.7V
0.07 sec/60°
857.1 deg/s
142.9 RPM
|
| Running Current | (add) |
| Stall Current | 0.24–0.31 A240–310 mA |
| Physical | |
| Weight | 0.06 oz1.7 g |
| Dimensions |
L 0.53 in W 0.24 in H 0.63 in L 13.5 mm W 6.1 mm H 16.0 mm |
| Case Material | Nylon / Fiberglass |
| Drivetrain | |
| Motor Type | Coreless |
| Motor Drive | (add) |
| Gears | Plastic |
| Gear Spline/Teeth | 25 T |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | Bushing |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | 90° |
| Mechanical Limit | 180° |
| Pulse Cycle | (add) |
| Pulse Width | 900-2100 µs |
| Neutral Position | (add) |
| Dead Band | 5 µs |
| Refresh Rate | (add) |
| Angle Sensor | Potentiometer |
| Control System | PWM |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 3.7–4.2 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | -10–50 °C14–122 °F |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | JR (Universal) |
| Wire Length | 110 mm4.33 in |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 0.02–0.04 W |
| Torque Density | 0.5294 oz-in/g Stronger than 0% of the 27 Flash Hobby servos in the database |
| Torque-to-Volume Ratio | 11.23 oz-in/in³ Denser torque than 0% of the 27 Flash Hobby servos in the database |
| Power Density | 0.480 W/in³ More power-dense than 23% of the 32 Digital Nano servos in the database |
| Speed-to-Weight | 8.40336 (1/sec·g) 1st-highest speed-to-weight of 27 Flash Hobby servos |
| Speed-Torque Trade-off | 0.06 Better balanced than 0% of the 27 Flash Hobby servos in the database |
| Current-per-Torque Ratio | 0.3444 A/oz-in More efficient than 8% of the 464 Hobby servos in the database |
| Torque Gain per Volt | 31.11%/V 1st-highest torque gain per volt of 24 Flash Hobby servos |
| Speed Gain per Volt | 80.01%/V 1st-highest speed gain per volt of 24 Flash Hobby servos |
| Voltage Range Width | 0.5 V Wider voltage range than 12% of the 26 Digital Nano servos in the database |
| Dead-Band-to-Pulse-Width Ratio | 0.0042 Finer dead band than 6% of the 644 Hobby servos in the database |
