Technical Specifications
Last Updated: 2026-10-25
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | DLP600 |
| Category | Hobby |
| Performance | |
| Torque |
7.4V
112.49 oz-in
8.10 kg-cm
0.8 N-m
6.0V
97.21 oz-in
7.00 kg-cm
0.7 N-m
|
| Speed |
7.4V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
6.0V
0.07 sec/60°
857.1 deg/s
142.9 RPM
|
| Physical | |
| Weight | 1.83 oz51.8 gAverage |
| Dimensions |
L 1.56 in W 0.79 in H 1.19 in L 39.6 mm W 20.1 mm H 30.2 mm |
| Case Material | Aluminum / Plastic |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Electrical & Environment | |
| Temperature | -10–60 °C14–140 °F |
| Connectivity | |
| Wire Length | 170 mm6.69 in |
| Origin | |
| Country of Origin | South Korea |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Average Lighter than 53% of 304 Digital Low Profile servos |
Performance Analysis
| Shaft Power | 2.57–3.47 W |
| Power Density | 2.364 W/in³ More power-dense than 32% of 273 Digital Low Profile servos |
| Torque Density | 1.8766 oz-in/g |
| Torque-to-Volume Ratio | 66.28 oz-in/in³ |
| Speed-to-Weight | 0.27579 (1/sec·g) |
| Speed-Torque Trade-off | 6.81 |
