Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | AAS-313 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
43.00 oz-in
3.10 kg-cm
0.3 N-m
4.8V
30.00 oz-in
2.16 kg-cm
0.2 N-m
|
| Speed |
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.15 sec/60°
400.0 deg/s
66.7 RPM
|
| Physical | |
| Weight | 0.47 oz13.2 gTop 10% |
| Dimensions |
L 1.10 in W 0.52 in H 1.12 in L 27.9 mm W 13.2 mm H 28.4 mm |
| Drivetrain | |
| Motor Type | 3-pole |
| Gears | Carbon |
| Rotation/Support | Single Bearing |
| Control & Signal | |
| Modulation | Analog |
| Rotational Range | 80° |
| Pulse Width | 1500-1900 µs |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Top 10% Lighter than 93% of 165 Analog Mini servos |
Performance Analysis
| Shaft Power | 0.37–0.66 W |
| Power Density | 1.034 W/in³ More power-dense than 72% of 163 Analog Mini servos |
| Torque Density | 2.2727 oz-in/g |
| Torque-to-Volume Ratio | 46.83 oz-in/in³ |
| Speed-to-Weight | 0.50505 (1/sec·g) |
| Speed-Torque Trade-off | 4.50 |
