Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | AAS-305BB |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
20.00 oz-in
1.44 kg-cm
0.1 N-m
4.8V
17.00 oz-in
1.22 kg-cm
0.1 N-m
|
| Speed |
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.13 sec/60°
461.5 deg/s
76.9 RPM
|
| Physical | |
| Weight | 0.22 oz6.2 gAverage |
| Dimensions |
L 0.92 in W 0.36 in H 0.90 in L 23.4 mm W 9.1 mm H 22.9 mm |
| Drivetrain | |
| Motor Type | 3-pole |
| Gears | Carbon |
| Rotation/Support | Single Bearing |
| Control & Signal | |
| Modulation | Analog |
| Rotational Range | 80° |
| Pulse Width | 1500-1900 µs |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Average Lighter than 63% of 346 Analog Micro servos |
Performance Analysis
| Shaft Power | 0.24–0.31 W |
| Power Density | 1.034 W/in³ More power-dense than 67% of 333 Analog Micro servos |
| Torque Density | 2.7419 oz-in/g |
| Torque-to-Volume Ratio | 57.03 oz-in/in³ |
| Speed-to-Weight | 1.24069 (1/sec·g) |
| Speed-Torque Trade-off | 2.21 |
