Technical Specifications
Last Updated: 2026-07-28
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
116.68 oz-in
8.40 kg-cm
0.8 N-m
7.4V
102.79 oz-in
7.40 kg-cm
0.7 N-m
6.0V
83.34 oz-in
6.00 kg-cm
0.6 N-m
|
| Speed |
8.4V
0.03 sec/60°
2,000.0 deg/s
333.3 RPM
7.4V
0.03 sec/60°
2,000.0 deg/s
333.3 RPM
6.0V
0.04 sec/60°
1,500.0 deg/s
250.0 RPM
|
| Running Current | (add) |
| Stall Current | (add) |
| Physical | |
| Weight | 2.47 oz70.0 g |
| Dimensions |
L 1.46 in W 0.79 in H 1.57 in L 37.1 mm W 20.1 mm H 39.9 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Motor Drive | (add) |
| Gears | Metal |
| Gear Spline/Teeth | (add) |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | (add) |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | (add) |
| Mechanical Limit | (add) |
| Pulse Cycle | (add) |
| Pulse Width | (add) |
| Neutral Position | 760 µs |
| Dead Band | (add) |
| Refresh Rate | 333 Hz |
| Angle Sensor | (add) |
| Control System | (add) |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | (add) |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | JR (Universal) estimate |
| Wire Length | (add) |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 3.85–7.19 W |
| Torque Density | 1.1906 oz-in/g Stronger than 8% of the 831 Digital Standard servos in the database |
| Torque-to-Volume Ratio | 46.02 oz-in/in³ Denser torque than 14% of the 842 Digital Standard servos in the database |
| Power Density | 3.971 W/in³ More power-dense than 71% of the 1643 Digital Standard servos in the database |
| Speed-to-Weight | 0.35714 (1/sec·g) Faster than 97% of the 820 Digital Standard servos in the database |
| Speed-Torque Trade-off | 3.33 Better balanced than 5% of the 825 Digital Standard servos in the database |
| Torque Gain per Volt | 16.67%/V More voltage-responsive (torque) than 60% of the 672 Digital Standard servos in the database |
| Speed Gain per Volt | 13.89%/V More voltage-responsive (speed) than 39% of the 686 Digital Standard servos in the database |
| Voltage Range Width | 2.4 V Wider voltage range than 48% of the 1268 Digital Standard servos in the database |
