Technical Specifications
Last Updated: 2026-07-10
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | Z-E0137 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
81.95 oz-in
5.90 kg-cm
0.6 N-m
4.8V
74.03 oz-in
5.33 kg-cm
0.5 N-m
|
| Speed |
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.14 sec/60°
428.6 deg/s
71.4 RPM
|
| Running Current | (add) |
| Stall Current | 1–1.2 A1000–1200 mA |
| Physical | |
| Weight | 0.37 oz10.5 g |
| Dimensions |
L 1.27 in W 0.46 in H 1.22 in L 32.3 mm W 11.7 mm H 31.0 mm |
| Case Material | (add) |
| Drivetrain | |
| Motor Type | (add) |
| Motor Drive | (add) |
| Gears | Metal |
| Gear Spline/Teeth | 21 T |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | (add) |
| Backlash | (add) |
| Control & Signal | |
| Modulation | (add) |
| Direction | (add) |
| Rotational Range | (add) |
| Mechanical Limit | (add) |
| Pulse Cycle | (add) |
| Pulse Width | 500-2500 µs |
| Neutral Position | (add) |
| Dead Band | (add) |
| Refresh Rate | (add) |
| Angle Sensor | (add) |
| Control System | PWM |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 4.8–6 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | (add) |
| Water Rating | None |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | (add) |
| Wire Length | (add) |
| Origin | |
| Country of Origin | USA |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 0.98–1.26 W |
| Torque Density | 7.0505 oz-in/g Stronger than 98% of the 308 Mini servos in the database |
| Torque-to-Volume Ratio | 103.87 oz-in/in³ Denser torque than 74% of the 313 Mini servos in the database |
| Power Density | 1.772 W/in³ More power-dense than 70% of the 677 Mini servos in the database |
| Speed-to-Weight | 0.68027 (1/sec·g) Faster than 91% of the 309 Mini servos in the database |
| Speed-Torque Trade-off | 10.36 Better balanced than 73% of the 313 Mini servos in the database |
| Current-per-Torque Ratio | 0.0162 A/oz-in More efficient than 91% of the 56 Mini servos in the database |
| Torque Gain per Volt | 8.92%/V More voltage-responsive (torque) than 10% of the 254 Mini servos in the database |
| Speed Gain per Volt | 13.88%/V More voltage-responsive (speed) than 30% of the 255 Mini servos in the database |
| Voltage Range Width | 1.2 V Wider voltage range than 7% of the 396 Mini servos in the database |
