Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | M0200 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V83.34 oz-in6.00 kg-cm0.6 N-m |
| Speed |
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.13 sec/60°
461.5 deg/s
76.9 RPM
Average
|
| Stall Current | ≤1.9 A≤1900 mABottom 10% |
| Physical | |
| Weight | 0.74 oz21.0 gAverage |
| Dimensions |
L 1.22 in W 0.65 in H 1.12 in L 31.0 mm W 16.5 mm H 28.4 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | DC |
| Gears | Metal |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Analog |
| Rotational Range | 120° |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Temperature | -10–50 °C14–122 °F |
| Water Rating | IP42 |
| Idle Current | 1.900 A1,900 mA |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Speed | Average Faster than 64% of 81 Analog Mini servos at 4.8V |
| Weight | Average Lighter than 39% of 165 Analog Mini servos |
| Stall Current | Bottom 10% Lower draw than 5% of 23 Analog Mini servos |
Performance Analysis
| Shaft Power | 1.28 W |
| Power Density | 1.446 W/in³ More power-dense than 92% of 163 Analog Mini servos |
| Torque Density | 3.9686 oz-in/g |
| Torque-to-Volume Ratio | 93.83 oz-in/in³ |
| Speed-to-Weight | 0.36630 (1/sec·g) Faster than 45% of 81 Analog Mini servos |
| Speed-Torque Trade-off | 10.84 |
| Current-per-Torque Ratio | 0.0228 A/oz-in |
| Voltage Range Width | 3.6 V 3rd-highest voltage range width of 88 Analog Mini servos |
