Technical Specifications
Last Updated: 2026-11-05
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | DP0090 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
25.00 oz-in
1.80 kg-cm
0.2 N-m
4.8V
22.20 oz-in
1.60 kg-cm
0.2 N-m
Below Average
|
| Speed |
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
4.8V
0.10 sec/60°
600.0 deg/s
100.0 RPM
Average
|
| Running Current |
6.0V
0.230 A
230 mA
4.8V
0.190 A
190 mA
Below Average
|
| Stall Current | ≤0.7 A≤700 mAAbove Average |
| Physical | |
| Weight | 0.32 oz9.0 gAverage |
| Dimensions |
L 0.88 in W 0.49 in H 0.91 in L 22.4 mm W 12.4 mm H 23.1 mm |
| Case Material | Plastic |
| Drivetrain | |
| Motor Type | Cored |
| Gears | Plastic |
| Rotation Mode | Positional |
| Rotation/Support | Bushing |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 120° |
| Pulse Width | 900-2100 µs |
| Dead Band | 6 µs |
| Refresh Rate | 333 Hz |
| Electrical & Environment | |
| Operating Voltage | 4.8–6 V |
| Temperature | -10–50 °C14–122 °F |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Below Average Stronger than 30% of 349 Digital Micro servos at 4.8V |
| Speed | Average Faster than 64% of 347 Digital Micro servos at 4.8V |
| Weight | Average Lighter than 64% of 597 Digital Micro servos |
| Running Current | Below Average Lower draw than 34% of 60 Digital Micro servos at 4.8V |
| Stall Current | Above Average Lower draw than 73% of 188 Digital Micro servos |
Performance Analysis
| Shaft Power | 0.41–0.51 W |
| Power Density | 1.309 W/in³ More power-dense than 30% of 563 Digital Micro servos |
| Torque Density | 2.4667 oz-in/g Stronger than 51% of 349 Digital Micro servos |
| Torque-to-Volume Ratio | 56.58 oz-in/in³ Denser torque than 27% of 345 Digital Micro servos |
| Speed-to-Weight | 1.11111 (1/sec·g) Faster than 78% of 347 Digital Micro servos |
| Speed-Torque Trade-off | 2.22 Better balanced than 29% of 345 Digital Micro servos |
| Current-per-Torque Ratio | 0.0315 A/oz-in More efficient than 61% of 98 Digital Micro servos |
| No-Load vs Stall Current Spread | 3.68 5th-highest no-load vs stall current spread of 45 Digital Micro servos |
| Torque Gain per Volt | 10.51%/V More voltage-responsive (torque) than 14% of 290 Digital Micro servos |
| Speed Gain per Volt | 9.26%/V More voltage-responsive (speed) than 6% of 295 Digital Micro servos |
| Voltage Range Width | 1.2 V Wider voltage range than 12% of 496 Digital Micro servos |
| Dead-Band-to-Pulse-Width Ratio | 0.0050 Finer dead band than 1% of 182 Digital Micro servos |
