Technical Specifications
Last Updated: 2026-10-25
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.013 |
| Category | Hobby |
| Performance | |
| Torque |
6.0V
30.56 oz-in
2.20 kg-cm
0.2 N-m
4.8V
27.78 oz-in
2.00 kg-cm
0.2 N-m
Above Average
|
| Speed |
6.0V
0.12 sec/60°
500.0 deg/s
83.3 RPM
4.8V
0.14 sec/60°
428.6 deg/s
71.4 RPM
Below Average
|
| Physical | |
| Weight | 0.46 oz13.0 gBelow Average |
| Dimensions |
L 0.93 in W 0.47 in H 1.13 in L 23.6 mm W 11.9 mm H 28.7 mm |
| Drivetrain | |
| Gears | Metal |
| Rotation/Support | Single Bearing |
| Control & Signal | |
| Modulation | Analog |
| Electrical & Environment | |
| Operating Voltage | 4.8–6 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 85% of 160 Analog Micro servos at 4.8V |
| Speed | Below Average Faster than 19% of 160 Analog Micro servos at 4.8V |
| Weight | Below Average Lighter than 14% of 336 Analog Micro servos |
Performance Analysis
| Shaft Power | 0.37–0.47 W |
| Power Density | 0.953 W/in³ More power-dense than 62% of 322 Analog Micro servos |
| Torque Density | 2.1369 oz-in/g Stronger than 52% of 160 Analog Micro servos |
| Torque-to-Volume Ratio | 56.24 oz-in/in³ Denser torque than 65% of 160 Analog Micro servos |
| Speed-to-Weight | 0.54945 (1/sec·g) Faster than 16% of 160 Analog Micro servos |
| Speed-Torque Trade-off | 3.89 Better balanced than 86% of 159 Analog Micro servos |
| Torque Gain per Volt | 8.34%/V More voltage-responsive (torque) than 11% of 101 Analog Micro servos |
| Speed Gain per Volt | 13.88%/V More voltage-responsive (speed) than 27% of 101 Analog Micro servos |
| Voltage Range Width | 1.2 V Wider voltage range than 19% of 174 Analog Micro servos |
