Technical Specifications
Last Updated: 2026-10-25
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | KAV20.1035MG |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
222.24 oz-in
16.00 kg-cm
1.6 N-m
7.4V
208.35 oz-in
15.00 kg-cm
1.5 N-m
6.0V
166.68 oz-in
12.00 kg-cm
1.2 N-m
4.8V
138.90 oz-in
10.00 kg-cm
1.0 N-m
Top 10%
|
| Speed |
8.4V
0.08 sec/60°
750.0 deg/s
125.0 RPM
7.4V
0.09 sec/60°
666.7 deg/s
111.1 RPM
6.0V
0.11 sec/60°
545.5 deg/s
90.9 RPM
4.8V
0.13 sec/60°
480.0 deg/s
80.0 RPM
Average
|
| Physical | |
| Weight | 1.59 oz45.0 gBottom 10% |
| Dimensions |
L 1.40 in W 0.59 in H 1.15 in L 35.6 mm W 15.0 mm H 29.2 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Titanium |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 180° |
| Pulse Width | 900-2100 µs |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 4.8–8.4 V |
| Connectivity | |
| Connector | JR (Universal) estimate |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Top 10% Stronger than 92% of 290 Digital Mini servos at 4.8V |
| Speed | Average Faster than 45% of 293 Digital Mini servos at 4.8V |
| Weight | Bottom 10% Lighter than 4% of 505 Digital Mini servos |
Performance Analysis
| Shaft Power | 2.05–5.14 W |
| Power Density | 5.407 W/in³ More power-dense than 87% of 482 Digital Mini servos |
| Torque Density | 3.0867 oz-in/g Stronger than 74% of 286 Digital Mini servos |
| Torque-to-Volume Ratio | 146.23 oz-in/in³ Denser torque than 86% of 288 Digital Mini servos |
| Speed-to-Weight | 0.17778 (1/sec·g) Faster than 7% of 289 Digital Mini servos |
| Speed-Torque Trade-off | 17.36 Better balanced than 92% of 288 Digital Mini servos |
| Torque Gain per Volt | 16.67%/V More voltage-responsive (torque) than 53% of 257 Digital Mini servos |
| Speed Gain per Volt | 15.63%/V More voltage-responsive (speed) than 46% of 262 Digital Mini servos |
| Voltage Range Width | 3.6 V Wider voltage range than 82% of 405 Digital Mini servos |
