Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | HS2000 |
| Category | Hobby |
| Performance | |
| Torque |
7.4V
362.46 oz-in
26.10 kg-cm
2.6 N-m
6.0V
297.19 oz-in
21.40 kg-cm
2.1 N-m
Above Average
|
| Speed |
7.4V
0.07 sec/60°
857.1 deg/s
142.9 RPM
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
Above Average
|
| Physical | |
| Weight | 2.63 oz74.6 gBelow Average |
| Dimensions |
L 1.56 in W 0.79 in H 1.52 in L 39.6 mm W 20.1 mm H 38.6 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation Mode | Positional |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Neutral Position | 1520 µs |
| Refresh Rate | 330 Hz |
| Control System | PWM |
| Electrical & Environment | |
| Operating Voltage | 6–7.4 V |
| Temperature | -10–60 °C14–140 °F |
| Connectivity | |
| Wire Length | 300 mm11.81 in |
| Origin | |
| Country of Origin | South Korea |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 67% of 1060 Digital Standard servos at 6.0V |
| Speed | Above Average Faster than 82% of 1045 Digital Standard servos at 6.0V |
| Weight | Below Average Lighter than 22% of 1880 Digital Standard servos |
Performance Analysis
| Shaft Power | 6.11–9.57 W |
| Power Density | 5.111 W/in³ More power-dense than 80% of 1768 Digital Standard servos |
| Torque Density | 3.9838 oz-in/g Stronger than 60% of 1053 Digital Standard servos |
| Torque-to-Volume Ratio | 158.65 oz-in/in³ Denser torque than 69% of 1058 Digital Standard servos |
| Speed-to-Weight | 0.14894 (1/sec·g) Faster than 73% of 1038 Digital Standard servos |
| Speed-Torque Trade-off | 26.75 Better balanced than 47% of 1034 Digital Standard servos |
| Torque Gain per Volt | 15.69%/V More voltage-responsive (torque) than 49% of 873 Digital Standard servos |
| Speed Gain per Volt | 20.40%/V More voltage-responsive (speed) than 79% of 874 Digital Standard servos |
| Voltage Range Width | 1.4 V Wider voltage range than 27% of 1560 Digital Standard servos |
