Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | HG800 |
| Category | Hobby |
| Performance | |
| Torque |
7.4V
115.27 oz-in
8.30 kg-cm
0.8 N-m
6.0V
93.05 oz-in
6.70 kg-cm
0.7 N-m
|
| Speed |
7.4V
0.04 sec/60°
1,500.0 deg/s
250.0 RPM
6.0V
0.05 sec/60°
1,200.0 deg/s
200.0 RPM
|
| Physical | |
| Weight | 2.19 oz62.0 gAverage |
| Dimensions |
L 1.56 in W 0.79 in H 1.52 in L 39.6 mm W 20.1 mm H 38.6 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Metal |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Pulse Cycle | 3.003 ms |
| Electrical & Environment | |
| Operating Voltage | 4.8–6 V |
| Temperature | -10–60 °C14–140 °F |
| Connectivity | |
| Wire Length | 300 mm11.81 in |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Average Lighter than 51% of 1902 Digital Standard servos |
Performance Analysis
| Shaft Power | 3.44–5.33 W |
| Power Density | 2.844 W/in³ More power-dense than 57% of 1759 Digital Standard servos |
| Torque Density | 1.5008 oz-in/g |
| Torque-to-Volume Ratio | 49.67 oz-in/in³ |
| Speed-to-Weight | 0.32258 (1/sec·g) |
| Speed-Torque Trade-off | 4.65 |
| Voltage Range Width | 1.2 V Wider voltage range than 7% of 1539 Digital Standard servos |
