Technical Specifications
Last Updated: 2026-07-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | B500H |
| Category | Hobby |
| Performance | |
| Torque |
7.4V
186.09 oz-in
13.40 kg-cm
1.3 N-m
6.0V
161.09 oz-in
11.60 kg-cm
1.1 N-m
|
| Speed |
7.4V
0.06 sec/60°
1,000.0 deg/s
166.7 RPM
6.0V
0.08 sec/60°
750.0 deg/s
125.0 RPM
|
| Physical | |
| Weight | 1.57 oz44.5 gBottom 10% |
| Dimensions |
L 1.34 in W 0.61 in H 1.21 in L 34.0 mm W 15.5 mm H 30.7 mm |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Metal |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Weight | Bottom 10% Lighter than 5% of 466 Digital Mini servos |
Performance Analysis
| Shaft Power | 3.72–5.73 W |
| Power Density | 5.798 W/in³ More power-dense than 89% of 440 Digital Mini servos |
| Torque Density | 3.6200 oz-in/g |
| Torque-to-Volume Ratio | 162.87 oz-in/in³ |
| Speed-to-Weight | 0.28090 (1/sec·g) |
| Speed-Torque Trade-off | 12.89 |
