Technical Specifications
Last Updated: 2026-07-28
|
Identity
Performance
Physical
Drivetrain
Control & Signal
Electrical & Environment
Connectivity
Origin
Preferences are saved automatically.
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | (add) |
| Category | Hobby |
| Performance | |
| Torque |
7.0V
486.05 oz-in
35.00 kg-cm
3.4 N-m
6.0V
416.61 oz-in
30.00 kg-cm
2.9 N-m
5.0V
345.79 oz-in
24.90 kg-cm
2.4 N-m
|
| Speed |
7.0V
0.25 sec/60°
240.0 deg/s
40.0 RPM
6.0V
0.30 sec/60°
200.0 deg/s
33.3 RPM
5.0V
0.37 sec/60°
162.2 deg/s
27.0 RPM
|
| Running Current | (add) |
| Stall Current | 3.5–4 A3500–4000 mA |
| Physical | |
| Weight | 2.75 oz78.0 g |
| Dimensions |
L 1.57 in W 0.79 in H 1.59 in L 39.9 mm W 20.1 mm H 40.4 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Cored |
| Motor Drive | MOS |
| Gears | Metal |
| Gear Spline/Teeth | 25 T |
| Shaft Size | (add) |
| Rotation Mode | (add) |
| Rotation/Support | Dual Bearings |
| Backlash | (add) |
| Control & Signal | |
| Modulation | Digital |
| Direction | (add) |
| Rotational Range | 180° |
| Mechanical Limit | 180° |
| Pulse Cycle | (add) |
| Pulse Width | 500-2500 µs |
| Neutral Position | 1500 µs |
| Dead Band | 2 µs |
| Refresh Rate | (add) |
| Angle Sensor | Potentiometer |
| Control System | PWM |
| Programmable | (add) |
| Signal Voltage | (add) |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Power Source | (add) |
| Regulator Type | (add) |
| Temperature | -20–60 °C-4–140 °F |
| Water Rating | Waterproof |
| Certification | (add) |
| Idle Current | (add) |
| Connectivity | |
| Connector | JR (Universal) |
| Wire Length | 300 mm11.81 in |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Performance Analysis
| Shaft Power | 1.73–3.59 W |
| Torque Density | 5.3412 oz-in/g Stronger than 81% of the 833 Digital Standard servos in the database |
| Torque-to-Volume Ratio | 211.25 oz-in/in³ Denser torque than 84% of the 844 Digital Standard servos in the database |
| Power Density | 1.823 W/in³ More power-dense than 41% of the 1645 Digital Standard servos in the database |
| Speed-to-Weight | 0.04274 (1/sec·g) Faster than 1% of the 822 Digital Standard servos in the database |
| Speed-Torque Trade-off | 124.98 Better balanced than 98% of the 827 Digital Standard servos in the database |
| Current-per-Torque Ratio | 0.0096 A/oz-in More efficient than 81% of the 232 Digital Standard servos in the database |
| Voltage Range Width | 2.4 V Wider voltage range than 49% of the 1271 Digital Standard servos in the database |
| Dead-Band-to-Pulse-Width Ratio | 0.0010 Finer dead band than 83% of the 329 Digital Standard servos in the database |
