Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | FHS29 |
| Category | Hobby |
| Performance | |
| Torque |
8.4V
694.50 oz-in
50.01 kg-cm
4.9 N-m
7.4V
625.05 oz-in
45.01 kg-cm
4.4 N-m
6.0V
527.82 oz-in
38.01 kg-cm
3.7 N-m
Top 10%
|
| Speed |
8.4V
0.11 sec/60°
545.5 deg/s
90.9 RPM
7.4V
0.12 sec/60°
500.0 deg/s
83.3 RPM
6.0V
0.15 sec/60°
400.0 deg/s
66.7 RPM
Average
|
| Physical | |
| Weight | 2.78 oz78.8 gBelow Average |
| Dimensions |
L 1.57 in W 0.79 in H 1.50 in L 39.9 mm W 20.1 mm H 38.1 mm |
| Case Material | Aluminum |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Steel |
| Gear Spline/Teeth | 25 T |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 180° |
| Pulse Width | 500-2500 µs |
| Angle Sensor | Magnetic Encoder |
| Control System | PWM |
| Programmable | Yes |
| Electrical & Environment | |
| Operating Voltage | 6–8.4 V |
| Water Rating | Waterproof |
| Connectivity | |
| Connector | JR (Universal) |
| Wire Length | 300 mm11.81 in |
| Origin | |
| Country of Origin | China |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Top 10% Stronger than 93% of 1043 Digital Standard servos at 6.0V |
| Speed | Average Faster than 37% of 1041 Digital Standard servos at 6.0V |
| Weight | Below Average Lighter than 14% of 1902 Digital Standard servos |
Performance Analysis
| Shaft Power | 6.51–11.67 W |
| Power Density | 6.275 W/in³ More power-dense than 86% of 1759 Digital Standard servos |
| Torque Density | 6.6982 oz-in/g Stronger than 91% of 1036 Digital Standard servos |
| Torque-to-Volume Ratio | 283.71 oz-in/in³ Denser torque than 93% of 1042 Digital Standard servos |
| Speed-to-Weight | 0.08460 (1/sec·g) Faster than 17% of 1033 Digital Standard servos |
| Speed-Torque Trade-off | 79.17 Better balanced than 91% of 1031 Digital Standard servos |
| Torque Gain per Volt | 13.16%/V More voltage-responsive (torque) than 33% of 850 Digital Standard servos |
| Speed Gain per Volt | 15.16%/V More voltage-responsive (speed) than 47% of 871 Digital Standard servos |
| Voltage Range Width | 2.4 V Wider voltage range than 50% of 1539 Digital Standard servos |
