Technical Specifications
Last Updated: 2026-10-26
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | ABDS-997HTG |
| Category | Hobby |
| Performance | |
| Torque |
7.4V
181.90 oz-in
13.10 kg-cm
1.3 N-m
6.0V
135.00 oz-in
9.72 kg-cm
1.0 N-m
Below Average
4.8V
92.00 oz-in
6.62 kg-cm
0.6 N-m
|
| Speed |
7.4V
0.07 sec/60°
857.1 deg/s
142.9 RPM
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
Above Average
4.8V
0.11 sec/60°
545.5 deg/s
90.9 RPM
|
| Physical | |
| Weight | 2.05 oz58.0 gAbove Average |
| Dimensions |
L 1.56 in W 0.74 in H 1.54 in L 39.6 mm W 18.8 mm H 39.1 mm |
| Drivetrain | |
| Motor Type | Brushless |
| Gears | Titanium |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Digital |
| Rotational Range | 80° |
| Pulse Width | 1500-2000 µs |
| Electrical & Environment | |
| Operating Voltage | 6–7.4 V |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Below Average Stronger than 28% of 1060 Digital Standard servos at 6.0V |
| Speed | Above Average Faster than 82% of 1045 Digital Standard servos at 6.0V |
| Weight | Above Average Lighter than 66% of 1880 Digital Standard servos |
Performance Analysis
| Shaft Power | 1.55–4.80 W |
| Power Density | 2.703 W/in³ More power-dense than 56% of 1768 Digital Standard servos |
| Torque Density | 2.3276 oz-in/g Stronger than 28% of 1053 Digital Standard servos |
| Torque-to-Volume Ratio | 75.94 oz-in/in³ Denser torque than 30% of 1058 Digital Standard servos |
| Speed-to-Weight | 0.19157 (1/sec·g) Faster than 86% of 1038 Digital Standard servos |
| Speed-Torque Trade-off | 12.15 Better balanced than 17% of 1034 Digital Standard servos |
| Torque Gain per Volt | 24.81%/V More voltage-responsive (torque) than 92% of 873 Digital Standard servos |
| Speed Gain per Volt | 20.40%/V More voltage-responsive (speed) than 78% of 874 Digital Standard servos |
| Voltage Range Width | 1.4 V Wider voltage range than 26% of 1560 Digital Standard servos |
