Technical Specifications
Last Updated: 2026-10-10
Weight
Dimensions
Torque
Speed
Current
Temp
Wire
| Identity | |
| Brand |  |
| Product Number | P-AAS752MG |
| Category | Hobby |
| Discontinued | Yes |
| Performance | |
| Torque |
6.0V
154.00 oz-in
11.09 kg-cm
1.1 N-m
4.8V
126.00 oz-in
9.07 kg-cm
0.9 N-m
Above Average
|
| Speed |
6.0V
0.09 sec/60°
666.7 deg/s
111.1 RPM
4.8V
0.11 sec/60°
545.5 deg/s
90.9 RPM
Top 10%
|
| Physical | |
| Weight | 1.69 oz48.0 gAverage |
| Dimensions |
L 1.56 in W 0.74 in H 1.54 in L 39.6 mm W 18.8 mm H 39.1 mm |
| Drivetrain | |
| Motor Type | Coreless |
| Gears | Metal |
| Rotation/Support | Dual Bearings |
| Control & Signal | |
| Modulation | Analog |
| Rotational Range | 80° |
| Pulse Width | 1500-2000 µs |
| Electrical & Environment | |
| Operating Voltage | 4.8–6 V |
Disclaimer: Most data is sourced from the manufacturer. Some data is sourced from our loyal community and with the help of AI. We aim for accuracy but are not responsible for inaccurate information.
Class Comparison
| Torque | Above Average Stronger than 77% of 192 Analog Standard servos at 4.8V |
| Speed | Top 10% Faster than 98% of 190 Analog Standard servos at 4.8V |
| Weight | Average Lighter than 51% of 448 Analog Standard servos |
Performance Analysis
| Shaft Power | 2.12–3.16 W |
| Power Density | 1.780 W/in³ More power-dense than 97% of 437 Analog Standard servos |
| Torque Density | 2.6250 oz-in/g Stronger than 81% of 192 Analog Standard servos |
| Torque-to-Volume Ratio | 70.88 oz-in/in³ Denser torque than 81% of 192 Analog Standard servos |
| Speed-to-Weight | 0.18939 (1/sec·g) Faster than 94% of 190 Analog Standard servos |
| Speed-Torque Trade-off | 13.86 Better balanced than 51% of 190 Analog Standard servos |
| Torque Gain per Volt | 18.52%/V More voltage-responsive (torque) than 68% of 145 Analog Standard servos |
| Speed Gain per Volt | 18.52%/V More voltage-responsive (speed) than 68% of 147 Analog Standard servos |
| Voltage Range Width | 1.2 V Wider voltage range than 9% of 229 Analog Standard servos |
